Cam-Type Self-Centering Beveling Machine

Quick-Clamp OD-Mounted Beveler

Cam-Type Self-Centering Beveling Machine

Self-centering OD-mounted pipe bevelers for 14-114mm tubes. Cam-lever quick clamping for fastest setup in HVAC, plumbing, and light industrial applications.

Pipe OD Range 14-114mm

Wall Thickness Up to 12mm

Clamping Cam-Lever Self-Centering

Models Available 2 Models

Available Drives:

SCB - Electric SCP - Pneumatic

Cold Cutting CE Certified 1-Year Warranty OEM Available

Talk via WhatsApp

Compare Models View Full Technical Data

Watch the CAM Series lock onto irregular plate edges and create consistent bevels

Overview

The Cam-Type Series delivers the fastest setup time of any portable pipe beveling machine. Its innovative cam-lever mechanism centers and clamps in one smooth action—no block changes, no screw adjustments, just position and clamp. Perfect for contractors and fabricators who value speed without sacrificing quality.

Key Advantages

One-action clamping - Fastest setup time in the industry (5-10 seconds)
Self-centering - Automatic alignment to any pipe size within range
Lightweight aluminum - Easy handling at only 13-18kg
Variable speed - Adaptable to different materials and thicknesses

The Cam-Lever Advantage

Traditional OD clamps require multiple steps: position, adjust screws, check centering, re-adjust. Cam-Type simplifies to one step: position machine, flip cam lever — done.

Speed Comparison

Machine Type	Setup Time	Best For
Cam-Type	5-10 sec	High volume, varied sizes
ISC Block	30-60 sec	Repetitive single size
SOC Chuck	15-25 sec	Larger pipes, mixed sizes

Which Model Should You Choose?

For HVAC, plumbing, and light mechanical (under 63mm OD):
The SCB/SCP-63 is perfect for mechanical contractors working primarily with 1/2”-2” pipes. At just 13kg, it’s easy to carry between floors and job sites. Handles 90% of commercial plumbing and HVAC work.

For process piping and larger installations (57-114mm OD):
Choose the SCB/SCP-114 for industrial facilities, fire protection systems, and general fabrication. The broader range means one machine covers 2”-4” pipes without switching.

Not sure which size?
If your work spans both ranges frequently, having both models maximizes efficiency—use the lighter 63 for small pipes, the 114 for larger work. Many contractors find this two-model approach ideal.

Drive Options

Drive Code	Type	Best For
SCB	Electric (220V)	Normal workshop, accessible power
SCP	Pneumatic	Outdoor, hazardous areas, marine

Technical Highlights

Variable Speed (30-120 r/min)

High speed (100-120): Thin wall carbon steel
Medium speed (60-90): Standard wall, stainless
Low speed (30-50): Thick wall, tough alloys

Aluminum Construction

High-strength alloy body
40% lighter than steel equivalents
Corrosion resistant

Customization Options

Bevel Angle — Standard angles (30°, 45°), custom angles on request
Drive System — Electric (SCB) or pneumatic (SCP) options
Voltage — 220V/50Hz standard, other configurations available
Tooling — Spare cutter inserts and heavy-duty blades available

Model Comparison

Quick comparison of key specifications. For complete technical data, see full specifications .

Model	OD Range (mm)	Wall Thickness (mm)	Bevel Angle (°)	Rotation Speed (r/min)
SCB/SCP-63	14-63 mm	≤12 mm	0-45 °	30-120 r/min
SCB/SCP-114	57-114 mm	≤12 mm	0-45 °	30-120 r/min

Need Complete Technical Specifications?

View all parameters including dimensions, tolerances, and downloadable datasheets.

View Full Specifications

Key Features

One-Action Cam Clamping

Cam-lever mechanism centers and clamps in a single motion - the fastest setup of any portable beveler.

Self-Centering Design

Automatically aligns to pipe center regardless of diameter within range, no adjustment needed.

Lightweight Aluminum Body

Aircraft-grade aluminum construction keeps weight under 18kg while maintaining rigidity.

Variable Speed Control

Adjustable 30-120 r/min rotation speed adapts to different pipe materials and wall thicknesses.

Simultaneous Cut & Bevel

Performs cutting and beveling in one operation, dramatically improving processing efficiency.

Cold Processing

No sparks, no heat-affected zone, preserves material properties and allows work in sensitive areas.

Industry Applications

Heavy Manufacturing

Industrial Equipment & Machinery Fabrication

Steel Construction

Bridges, Buildings & Infrastructure Projects

Pressure Vessels

Tanks, Boilers & Pressure Equipment Fabrication

Power & Energy

Boiler Tubes, Steam Lines & Energy Facility Piping

Frequently Asked Questions

How does Cam-Type compare to ISC Block Type?

Cam-Type is faster to set up (one-action clamp vs. block change) and covers wider range per model. ISC Block Type offers more rigid clamping for critical precision work. Choose Cam for speed, ISC for maximum stability.

Can both models cover the 57-63mm overlap range?

Yes, both SCB-63 (14-63mm) and SCB-114 (57-114mm) cover this range. Use the 63 model for lighter weight, or the 114 model if you work mostly with larger pipes.

What's the difference between SCB and SCP?

SCB is electric-powered (standard), SCP is pneumatic. Same clamping mechanism and capability, different power source. Choose SCP for hazardous areas or where compressed air is more convenient.

Is this suitable for stainless steel?

Yes, with appropriate speed adjustment (lower RPM) and carbide inserts designed for stainless. Works on carbon steel, stainless, copper, and aluminum.

How long does a typical bevel take?

With one-action clamping, total cycle time is typically 20-45 seconds including setup. The actual cutting takes 10-20 seconds depending on wall thickness.

What power supply is required?

Electric models (SCB) use 220V AC. Pneumatic models (SCP) require 0.6-0.8 MPa compressed air at 800-1200 L/min.

Can I switch between electric and pneumatic?

The motor units are interchangeable on the same body. You can purchase both drive types and swap based on job requirements.
